APC Smart-UPS RT 1000VA 1kva 230V SURT1000XLI
APC Smart-UPS RT 1000VA 1kva 230V SURT1000XLI
SURT1000XLI “APC Smart-UPS RT 1000VA 230V Features : High density, double-conversion on-line power protection with scalable runtime;
2 years repair or replace, optional on-site warranties available, optional extended warranties available
APC Smart-UPS RT 1000VA 1kva 230V SURT1000XLI
APC Smart-UPS RT 1000VA 1kva 230V SURT1000XLI Provides pure sine wave output which is recommended by server manufacturers using active power factor corrected (PFC) power supplies.
APC Smart-UPS RT 1000VA UPS Safety agency tested and approved means that you can deploy Smart-UPS with confidence that they meet or exceed the industry’s most rigorous standards.
1KVA APC Smart-UPS RT Intelligent battery management, pioneered bmaximizes battery performance and life through intelligent, precision temperature compensated charging. Automatic self-tests ensure battery reliability and warn customers in advance of battery replacement.
1000 VA APC Smart-UPS Network manageable via serial, USB or Ethernet. Includes Powerchute® Software for convenient monitoring and control, safe operating system shutdown, and innovative energy management capabilities.
1KVA APC Smart-UPS specification
Output
Output power capacity
700Watts / 1.0kVA
Max Configurable Power (Watts)
700Watts / 1.0kVA
Nominal Output Voltage
230V
Output Voltage Note
Configurable for 220 : 230 or 240 nominal output voltage
Output Voltage Distortion
Less than 3%
Output Frequency (sync to mains)
50/60 Hz +/- 3 Hz user adjustable +/- 0.1
Other Output Voltages
220, 240
Load Crest Factor
3 : 1
Topology
Double Conversion Online
Waveform type
Sine wave
Output Connections
(6) IEC 320 C13 (Battery Backup)
(2) IEC Jumpers (Battery Backup)
Bypass
Built-in Bypass
Input
Nominal Input Voltage
230V
Input frequency
50/60 Hz +/- 5 Hz (auto sensing)
Input Connections
IEC-320 C14
Input voltage range for main operations
160 – 280V
Input voltage adjustable range for mains operation
100 – 280V
Number of Power Cords
1
Other Input Voltages
220, 240
Batteries & Runtime
Battery type
Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof
Included Battery Modules
1
Typical recharge time
3hour(s)
Replacement Battery
RBC31
Expected Battery Life (years)
3 – 5
RBC Quantity
1
Extendable Run Time
1
Extended Run Options
APC-Smart-UPS-RT-1000VA-230V
Runtime
View Runtime Chart
Efficiency
Communications & Management
Interface Port(s)
DB-9 RS-232, SmartSlot
Control panel
LED status display with load and battery bar-graphs and On Line : On Battery : Replace Battery : Overload and Bypass Indicators
Audible Alarm
Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
Emergency Power Off (EPO)
Optional
Available SmartSlot™ Interface Quantity
1
Surge Protection and Filtering
Surge energy rating
420Joules
Filtering
Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449
Physical
Maximum Height
432MM, 43.2CM
Maximum Width
85MM, 8.5CM
Maximum Depth
483MM, 48.3CM
Rack Height
2U
Net Weight
23.0KG
Shipping weight
27.8KG
Shipping Height
286MM, 28.6CM
Shipping Width
630MM, 63.0CM
Shipping Depth
594MM, 59.4CM
Color
Black
Master Carton Units
1.0
Units per Pallet
6.0
Environmental
Operating Temperature
0 – 40 °C
Operating Relative Humidity
0 – 95 (non-condensing) %
Operating Elevation
0-3000meters
Storage Temperature
-20 – 50 °C
Storage Relative Humidity
0 – 95 (non-condensing) %
Storage Elevation
0-15000meters
Audible noise at 1 meter from surface of unit
50.0dBA
Online thermal dissipation
324.0BTU/hr
Protection Class
IP 20
Conformance
Approvals
C-tick, CE, EN 50091-1, EN 50091-2, EN 55022 Class A, EN 60950, EN 61000-3-2, GOST, VDE
Standard warranty
2 years repair or replace, optional on-site warranties available, optional extended warranties available
Sustainable Offer Status
RoHS
Compliant
REACH
