Grandstream GWN7701PA Unmanaged Network Switch

Grandstream GWN7701PA Unmanaged Network Switch

The Grandstream GWN7701PA is an unmanaged, compact Gigabit Ethernet network switch designed to provide reliable wired connectivity and power for PoE-enabled devices. Supporting 8 ports with full Gigabit speeds and 4 ports delivering IEEE 802.3af/at PoE+ with an enhanced 123 W total PoE budget, this switch is perfect for small to medium businesses needing efficient, plug-and-play network expansion without configuration complexity.

Grandstream GWN7701PA Unmanaged Network Switch Specifications

• Ports: 8 × 10/100/1000 Mbps Gigabit Ethernet ports

• PoE Support: 4 ports with IEEE 802.3af/at PoE+

• Total PoE Budget: 123 W

• Switch Type: Unmanaged (plug and play, no setup required)

• Switching Capacity: 16 Gbps

• Forwarding Rate: 11.9 Mpps (million packets per second)

• MAC Address Table: 8K entries

• Jumbo Frame Support: Up to 9 KBhttps://www.city.co.ke

• Power Input: External power adapter, 100-240 V AC

• Power Consumption: Max ~130 W (including PoE)

• Fanless Design: Silent operation

• Dimensions: Approx. 210 × 150 × 30 mm

• Operating Temperature: 0°C to 40°Chttps://www.city.co.ke

• Certifications: FCC, CE, IC, RoHS

• Warranty: Typically 1-year manufacturer warranty
