6m Traffic Barrier Centurion Sector II

The Centurion Sector II 6m Traffic Barrier is a premium, high-performance vehicle barrier system designed for wide entrances and high-volume traffic areas such as industrial sites, logistics hubs, gated communities, office complexes, and toll gates. Built for strength, speed, and durability, it effortlessly controls access over roadways up to 6 meters wide.

6m Traffic Barrier Centurion Sector II Specifications

• Boom arm length: 6 meters

• Motor type: 24V DC high-torque motor with intelligent speed control

• Input voltage: 90–250V AC (wide range, 50/60Hz)

• Opening speed: Adjustable, typically 2.5 to 3.5 seconds for full travel

• Duty cycle: Rated for continuous operation (up to 3000 operations/day)

• Boom type: Aluminium pole, round or hexagonal, with reflective decals and optional LED strip

• Chassis: Powder-coated mild steel, corrosion-resistant for outdoor use

• Controller: Built-in SMART logic controller with diagnostics, event logging, and timers

• Battery backup: Standard with built-in charger and two 12V batteries

• Obstacle detection: Electronic torque sensing with auto-reverse

• Safety integration: Compatible with loop detectors, infrared beams, and safety edge sensors

• Access control inputs: Push-button, remote control, GSM, RFID, tag readers, keypads, biometric devices

• Environmental resistance: Internal cooling fan, sealed controller housing

• Operating temperature: –15°C to +55°C

• Mounting: Surface mount on concrete slab

• Housing dimensions: Approx. 340mm (W) × 1030mm (H) × 310mm (D)

• Weight: ±38–42 kg (excluding boom and mounting kit)
