- Pure sine wave inverter
- Enhance AC charger to 60A
- Wide battery input range
- Selectable input voltage range for home appliances and personal computers
- Selectable high power charging current
- Configurable AC/Solar input priority via LCD setting
- Compatible to mains voltage or generator power
- Auto restart while AC is recovering
- Overload and short circuit protection
- Smart battery charger design for optimized battery performance
- Cold start function
| Model | Axpert EX 1.5K-12 | Axpert EX 1.5K-24 | Axpert EX 3K-24 |
| RATED POWER | 1500VA/1200W | 1500VA/1200W | 3000VA/2400W |
| INPUT | |||
| Voltage | 220/230/240 VAC | ||
| Selectable Voltage Range | 170-280 VAC (For Personal Computers) ; 90-280 VAC (For Home Appliances) | ||
| Frequency Range | 50 Hz/60 Hz (Auto sensing) | ||
| OUTPUT | |||
| AC Voltage Regulation (Batt. Mode) | 220/230/240VAC ± 5% | ||
| Surge Power | 3000VA | 3000VA | 6000VA |
| Efficiency (Peak) | 90% ~ 93% | ||
| Transfer Time | 10 ms (For Personal Computers) ; 20 ms (For Home Appliances) | ||
| Waveform | Pure sine wave | ||
| BATTERY | |||
| Battery Voltage | 12 VDC | 24 VDC | |
| Floating Charge Voltage | 13.5 VDC | 27 VDC | |
| Overcharge Protection | 16 VDC | 32 VDC | |
| SOLAR CHARGER & AC CHARGER | |||
| Maximum PV Array Open Circuit Voltage | 50VDC | 75VDC | |
| Maxmum Solar Charge Current | 50A | ||
| Maximum AC Charge Current | 60 A | ||
| Maximum Charge Current | 110 A | ||
| PHYSICAL | |||
| Dimension, D x W x H (mm) | 100 x 272 x 355 | ||
| Net Weight (kgs) | 6.6 | ||
| OPERATING ENVIRONMENT | |||
| Humidity | 5% to 95% Relative Humidity(Non-condensing) | ||
| Operating Temperature | -20°C – 55°C | ||
| Storage Temperature | -30°C – 60°C | ||
| Product specifications are subject to change without further notice. |
